Ultrasonic method

“Ultrasonic soldering method & theory”
Bonding to unbondable materials: Deliveredd by ultrasonic wave

Ultrasonic soldering turns conventional wisdom upside down. Soldering even on glass or ceramics

Soldering conventionally involves bonding solder (tin) with a metallic substrate. Ultrasonic soldering method is an advanced way that enables solder to bond with glass or non-metallic materials. As renewable energy sources are attaining widespread use around the world, electrodes are being affixed to solar voltaic panels. Ultrasonic soldering has been adopted for this application.
This section explains the theory of ultrasonic soldering method that is now garnering renewed attention.

One ultrasonic soldering utilizes two different principles

Records show that ultrasonic soldering was originally developed in 1961. It enables soldering on materials that were originally nearly unsolderable, such as aluminum or stainless steel, and onto completely unsolderable non-metallic surfaces such as glass, ceramics, and alumite. However, the bonding principles are markedly different for each of these materials.

Ultrasonic soldering: Ultrasonic soldering robot Soldering onto a glass surface

Ultrasonic soldering
Ultrasonic soldering robot Soldering onto a glass surface

Demonstration of ultrasonic soldering onto a glass surface.

Ultrasonic soldering: Ultrasonic soldering robot Ultrasonic action

Ultrasonic soldering
Ultrasonic soldering robot Ultrasonic action

Soldering onto glass with and without ultrasonic. The ultrasonic action is immediately obvious.

Aluminum and stainless have a strong oxide layer. Even today, strong acidic flux is used to remove the oxide skin for special soldering on aluminum and other materials. However, today’s environmental regulations have driven a trend to avoid the use of highly-polluting halogen materials. On one hand, glass and aluminum are themselves oxidized materials, thus, conventional iron tip soldering principle cannot apply.

Ultrasonic wave : Cavitation phenomenon ”the power of 1/50,000 sec.”

When ultrasonic wave vibrations are applied to a liquid, small cavities are produced in bubble form due to pressure differences within the flow. This phenomenon is called cavitation. The cavities are collapsed by atmospheric pressure. A large amount of energy is generated during that 1/50,000 second. Ultrasonic soldering utilizes cavitation’s energy to enable the removal of the oxide skin. This is because it exploits this mechanism that obviates the need for flux in the soldering process.

Ultrasonic soldering robot: Visualization of ultrasonic cavitation

Ultrasonic soldering robot
Visualization of ultrasonic cavitation

World’s first successful imaging of ultrasonic cavitation during soldering. This confirms the generation of air bubbles.

– Scrubbing action of cavitation implosions (on metal) –

In an ultrasonic soldering system, soldering is done with a heated soldering tip that also simultaneously emits ultrasonic vibrations. The ultrasonic waves generated from oscillator are transferred to the soldering tip via a horn, producing cavitation bubbles at the interface between the substrate and the molten solder. The implosive energy of cavitation changes the oxide surface and removes dirt and the oxide layer. At the same time, an alloy layer is formed though melting and spreading action.

Soldering on an aluminum plate
(SEM: 6,000 X)
Solder-Aluminum plate (EDX)

– Bonding action through medium of oxygen (non-metallic) –

Glass and ceramic are themselves oxides, and cannot be bonded with conventional soldering mechanisms. Oxygen is incorporated while heat energy is simultaneously released in the instant when the ultrasonic cavitation bubbles collapse. It has been suggested that the molten solder’s metallic elements, with their strong chemical affinity to oxygen, use that energy and incorporated oxygen as the medium through which a shared bond is formed with the surface of the glass or similar material. (*1) Solder melted as a result of ultrasonic vibrations is sufficiently agitated so that the solder at the bonding surface is more readily able to incorporate oxygen to enable the formation of a stronger shared bond. The resulting geometric properties, chemical properties and bond strength are not inferior to ordinary solder.
(Reference: “A soldering technique for direct bonding of metal to glass” , Asahi Glass Research Labs, 1976 )

Soldering on a glass plate
(SEM: 10,000 X)
Bonding action through medium of oxygen (non-metallic)

– Expanding fields of ultrasonic application –

Starting with bonding of electrodes to glass in solar panels, there are many diverse fields in which ultrasonic soldering is used. MCUs that form the “brains” of an automobile are completely encased in aluminum to block external noise. ultrasonic soldering is used for soldering the aluminum. Recent years have seen an increase in instances of coils of aluminum wires replacing copper wires in motor coils and transmissions to reduce weight. ultrasonic soldering, with a mechanism that differs from laser and tip soldering. Its applications are expanding day by day, enabling work that had been impossible in the past.

“Special features”
  1. Bonding principle that makes use of cavitation phenomenon
  2. Removal of strong oxide layers is possible without flux
  3. Non-metallic soldering is possible by oxygen bonding
